3200B Baby Bushwheel Assemblies

The ABI 3200/3400 Baby Bushwheel Tailwheel Assembly stands out as a robust and versatile replacement for traditional Scott 3400 tailwheels, making it an exceptional choice for aircraft operating in rugged backcountry environments. Designed to excel in demanding conditions such as gravel, river rock, and sand, this assembly is tailored to meet the unique challenges of off-airport landings and takeoffs.

Diagram #	PN	Description
1	ABI-3216-00	Tailwheel Head
2	ABI-800613	2 Bolt Tailwheel Head
3	ABI-3241-3S	Spacer
4	ABI-3243-01	Leaf Spring Adapter 1 1/2"
5	ABI-3243-02	Leaf Spring Adapter 1 1/4"
6	ABI-3207-00	Fiber Thrust Washer
7	ABI-3234-00	Thrust Plate Assembly
8	ABI-3235-02	Dust Cap, Upper
9	ABI-3256-2	Dust Cap, Upper
10	ABI-3206-00	Thrust Washer
11	ABI-3219-02	Long Pawl
12	ABI-3219-00	Short Pawl
13	ABI-3214-00	Straight Steering Arm Assembly
14	ABI-3214T	Bent Steering Arm Assembly
15	ABI-3233-00	Compression Spring
16	ABI-3256-1	Dust Cap, Lower
17	ABI-3235-01	Dust Cap, Lower
18	ABI-3205-00	Bushing
19	ABI-3257-00	Pin
20	ABI-232-046	Dowel Pin
21	ABI-3258-00	Spacer
22	ABI-3222-00	Compression Spring
23	ABI-3258-01	Spacer
24	ABI-F1 K	Wide Tailwheel Fork
25	A4138-20629	Bearing Cup
26	A4050	Cone Bearing
27	ABI-2504-01	Spacer
28	ABI-1863	Bearing Grease Seal
29	AN960-816	Washer
30	AN320-8	Shear Nut
31	MS24665-283	COTTER PIN, 3/32" X 3/4"
32	T7201	Zerk Fitting
33	ABI-872	Axle Bolt - Wide Fork
34	ABI-3225-00	Tab Lock Washer
35	MS21044N4	NUT (Nylon Lock)
36	NAS1149F0463P	WASHER, 1/4, Steel, .063
37	ABI-3227-00	Spacer
38	ABI-3244K	Wheel Half
39	ABI-51167	Baby Bushwheel Grease Seal
40	ABI-S2	Rim Spacer (ABI-3200-B Tailwheels)
41	AN4-34A	Bolt, AN
42	AN310-8	NUT
43	11154.R	Baby Bushwheel Tailwheel Tire
