3400 Scott Replacement Tailwheel Assembly

The ABI 3200/3400 Baby Bushwheel Tailwheel Assembly stands out as a robust and versatile replacement for traditional Scott 3400 tailwheels, making it an exceptional choice for aircraft operating in rugged backcountry environments. Designed to excel in demanding conditions such as gravel, river rock, and sand, this assembly is tailored to meet the unique challenges of off-airport landings and takeoffs.

Diagram #	PN	Description
1	ABI-3216-00	Tailwheel Head
2	ABI-800613	2 Bolt Tailwheel Head
3	ABI-3241-3S	Spacer
4	ABI-3243-01	Leaf Spring Adapter 1 1/2"
5	ABI-3243-02	Leaf Spring Adapter 1 1/4"
6	ABI-3207-00	Fiber Thrust Washer
7	ABI-3234-00	Thrust Plate Assembly
8	ABI-3235-02	Dust Cap, Upper
9	ABI-3256-2	Dust Cap, Upper
10	ABI-3206-00	Thrust Washer
11	ABI-3219-02	Long Pawl
12	ABI-3219-00	Short Pawl
13	ABI-3214-00	Straight Steering Arm Assembly
14	ABI-3214T	Bent Steering Arm Assembly
15	ABI-3233-00	Compression Spring
16	ABI-3256-1	Dust Cap, Lower
17	ABI-3235-01	Dust Cap, Lower
18	ABI-3205-00	Bushing
19	ABI-3257-00	Pin
20	ABI-3258-00	Spacer
21	ABI-3222-00	Compression Spring
22	ABI-3258-01	Spacer
23	ABI-232-046	Dowel Pin
24	ABI-3224 K	8" Tailwheel Fork
25	A4138-20629	BEARING CUP, CL 2 CODE 629, FA
26	A4050-20629	BEARING CONE, CL2 CODE 629, FA
27	ABI-2504-01	Spacer
28	ABI-1863	Bearing Grease Seal
29	AN960-816	Washer
30	AN320-8	Shear Nut
31	MS24665-283	Cotter Pin
32	T7201	Zerk Fitting
33	ABI-3236	Axle Bolt
34	ABI-3225-00	Tab Lock Washer
35	MS21044N4	Locking Nut
36	AN960-416	Washer
37	ABI-3227-00	Spacer
38	ABI-3244 K	Wheel Half
39	ABI-2602	Gasket
40	AN4-7A	Bolt
41	AN310-8	Castle Nut
42	280/250-4 TUBE	280 x 2.50 x 4" Tube
43	280x250-4	Std. 8" Tailwheel Tire
