3400B Baby Bushwheel Tailwheel Assemblies

The ABI 3200/3400 Baby Bushwheel Tailwheel Assembly stands out as a robust and versatile replacement for traditional Scott 3400 tailwheels, making it an exceptional choice for aircraft operating in rugged backcountry environments. Designed to excel in demanding conditions such as gravel, river rock, and sand, this assembly is tailored to meet the unique challenges of off-airport landings and takeoffs.

Diagram #	PN	Description
1	ABI-3412-M K	Tailwheel Head
2	ABI-3412-S.1.00	1" Head Spacer
3	ABI-3412-S.937	15/16" Head Spacer
4	ABI-3412-S.875	7/8" Head Spacer
5	08231-20629	BEARING CUP, CL 2 CODE 629, FAA-PMA
6	08118-20629	BEARING CONE, CL 2 CODE 629, FAA-PMA
7	ABI-3233-00	Compression Spring
8	ABI-3411-02	Dust Cap, Upper
9	ABI-3411-07	Dust Cap, Upper (locking tailwheels)
10	ABI-3408-00	Thrust Washer
11	ABI-3408-01	.036 Fiber Thrust Washer
12	ABI-3219-02	Long Pawl
13	ABI-3219-00	Short Pawl
14	ABI-3410-05	Straight Steering Arm
15	ABI-3410-03	Steering Arm - Bent
16	ABI-3407-00	Spacer
17	ABI-3408-02	.065 Fiber Thrust Washer
18	ABI-3479-01	Fiber Thrust Washer (locking tailwheels)
19	ABI-3411-01	Dust Cap, Lower
20	ABI-3411-05	Dust Cap, Lower (locking tailwheels)
21	ABI-232-046	Dowel Pin
22	MS24693S272	3400 Plate Screw
23	ABI-SP34	Spacer Plate
24	ABI-3257-00	Pin
25	ABI-3258-00	Spacer
26	ABI-3432-00	Compression Spring
27	ABI-3258-01	Spacer
28	ABI-F2K	Spacer Plate
29	A4138-20629	BEARING CUP, CL 2 CODE 629, FA
30	A4050	Cone Bearing
31	ABI-2504-01	Spacer
32	ABI-1863	Bearing Grease Seal
33	AN960-816L	Washer
34	AN320-8	Shear Nut
35	MS24665-283	COTTER PIN, 3/32" X 3/4"
36	T7201	Zerk Fitting
37	ABI-872	Axle Bolt - Wide Fork
38	ABI-3225-00	Tab Lock Washer
39	MS21044N4	NUT (Nylon Lock)
40	NAS1149F0463P	WASHER, 1/4, Steel, .063
41	ABI-3227-00	Spacer
42	ABI-3244 K	Wheel Half
43	ABI-51167	Grease Seal
44	ABI-S2	Rim Spacer (ABI-3200-B Tailwheels)
45	AN4-34A	Bolt, AN
46	AN310-8	NUT
47	1154.R	Baby Bushwheel Tire
