BATTERY, Light Weight, Dry

P/N: 0769-4005

Jump to product details

Approval FAA PMA STC
Condition New
Manufacturer EnerSys Energy Products Inc.
Unit of Measure Each
Retail Price $336.35
Your Price $269.08
Stock Status In Stock

Share this product:

Supersedures

Please verify that this product is eligible for your aircraft before adding it to your cart.

Related Documents

Related Videos

EarthX- How To Charge Your Lithium Battery
Do EarthX lithium batteries explode?

Frequently Asked Questions

Eligible Aircraft

Make Series Model Beginning S/N Ending S/N Comment Eligibility Chart
Many Many Many 0 ZZZZZZZZZZZZZZZ
Piper PA-18 PA-18 18-1 18-7632 FAA-PMA approved with STC SA02138AK installed
Piper PA-18 PA-18-105 (Special) 18-1 18-7632 FAA-PMA approved with STC SA02138AK installed
Piper PA-18 PA-18-125 (Army L-21A) 18-1 18-7632 FAA-PMA approved with STC SA02138AK installed
Piper PA-18 PA-18-135 (Army L-21B) 18-1 18-7632 FAA-PMA approved with STC SA02138AK installed
Piper PA-18 PA-18-150 1809001 1809113 FAA-PMA approved with STC SA02138AK installed
Piper PA-18 PA-18-150 18-3771 18-8309025 FAA-PMA approved with STC SA02138AK installed
Piper PA-18 PA-18A 18-1 18-7632 FAA-PMA approved with STC SA02138AK installed
Piper PA-18 PA-18A-135 18-1 18-7632 FAA-PMA approved with STC SA02138AK installed
Piper PA-18 PA-18A-150 18-3771 18-8309025 FAA-PMA approved with STC SA02138AK installed
Piper PA-18 PA-18AS-125 18-1 18-7632 FAA-PMA approved with STC SA02138AK installed
Piper PA-18 PA-18AS-135 18-1 18-7632 FAA-PMA approved with STC SA02138AK installed
Piper PA-18 PA-18AS-150 18-3771 18-8309025 FAA-PMA approved with STC SA02138AK installed
Piper PA-18 PA-18S 18-1 18-7632 FAA-PMA approved with STC SA02138AK installed
Piper PA-18 PA-18S-105 (Special) 18-1 18-7632 FAA-PMA approved with STC SA02138AK installed
Piper PA-18 PA-18S-125 18-1 18-7632 FAA-PMA approved with STC SA02138AK installed
Piper PA-18 PA-18S-135 18-1 18-7632 FAA-PMA approved with STC SA02138AK installed
Piper PA-18 PA-18S-150 1809001 1809113 FAA-PMA approved with STC SA02138AK installed
Piper PA-18 PA-18S-150 18-3771 18-8309025 FAA-PMA approved with STC SA02138AK installed
Piper PA-19 PA-19 (Army L-18C) 19-1 19-3 FAA-PMA approved with STC SA02138AK installed
Piper PA-19 PA-19S 19-1 19-3 FAA-PMA approved with STC SA02138AK installed

Related Categories

Product Details

Note: This battery is FAA-PMA for PA18 and PA19 aircraft only when STC SA02138AK is installed.

Superior vibration resistance

  • Big power in a little box
  • Leak proof, high G rated
  • 12 year design life and 6 to 10 year service life
  • Saves 15 pounds!

Battery can be used with battery rack part numbers 3304 and 8008.

Construction:

  • Drycell design for mounting in any orientation and fully aerobatic use
  • 2 year storage life to 50% state of charge when stored at 77F (25C)
  • 70% of rated starting power delivered at -4F (-20C)
  • Military grade for excellent vibration resistance and high G loading
  • Delivers up to 60% more starting power as compared to equivalent size wet/flooded batteries
  • Non-spillable US DOT and IATA classification for safe shipping

Specifications:

  • 12 Volt
  • Length: 7.15 in (181.61 mm)
  • Width: 3.01 in (76.33 mm)
  • Height: 6.61 in (167.77 mm)
  • Weight: 15.4 lbs (6.99 kg)
  • Nominal capacity: 12.3 Ah @ C1
  • Nominal capacity: 16.0 Ah @ C/10
  • Altitude rating: -1,500 to 70,000 ft.
  • 5 second 80F (27C) cranking amps to 7.2V: 680 amps
  • CCA: 220 amps @ 0F (-17.8C)
  • CA: 300 amps @ 32F (0C)
  • HCA: 370 amps @ 80F (27C)
  • Reserve capacity: 25 minutes @ 25 amps
  • Terminals: Brass female for M6 stainless steel bolt
  • Terminal torque: 50 in-lb
  • Resistance: 7 mOhm at 1kHz @ 77F
  • Short circuit current: >1,800 amps
  • Material Safety Data Sheet
